66 Project (Pro Driver?)

[67-ls1]

Dash board without any gauges, ash tray or a glove box.
The next owner (grandson) asking “what this is for Papa?”
I did a complete color change on the interior from black to red.
New ProCar seats.
Painted seat tracks to blend in more with the carpet.
Registration back on after 20 years off the road!!

[67-ls1]

Air intake plenum behind drivers headlight.
Pypes 2.5” system with 50 series Flowmasters.

[67-ls1]

I’m playing with a front spoiler design. This is still a work in progress. I put it in a jig and heated the crap out of it. It helped some but I probably needed to be more aggressive with the bends and heat.

[67-ls1]

So after driving a few thousand miles and lowering the car a little more, the driveshaft rubbed the floor when carrying a passenger. I had already enlarged the trans tunnel and the forward part of the driveshaft tunnel but didn’t go back far enough.
So I’ve gutted the interior again and cut the floor out from the trans output flange all the way back to where it kicks up to the trunk.

[67-ls1]

Cutout all the way to the back and now the tunnel is going back in. The tunnel under the back seat is flat topped to make the seat frame mods easier. Hopefully.
The complete tunnel will give me just under 3” more inches of clearance.
I’m still working on this so I’ll post more pics as I progress.
I still need to build a mount for the shifter and a mount for the custom console. A stock console would never fit these new floor boards.
And I’ll need to strip the rear seat back down to a bare frame and modify the frame to clear the new larger tunnel.

[67-ls1]

I have literally 1000’s of additional pics if anyone wants anymore detailed photos of any aspect of my project. Or just questions...

[67-ls1]

I’ve carefully removed the upholstrey from the back seat to modify the seat frame to clear the new taller driveshaft tunnel. The frame is 3/16” rod so I fab’d up some pieces 2” taller and welded them in. The front edge where the upholstrey attaches with hog rings I fab’d up by shrinking, stretching and welding a piece of 18 gauge.

[67-ls1]

I had an annoying rattle in the dash so I pulled the dash back out, refastened everything, put jute on every surface so if any wire does wiggle loose it won’t hit anything.

[67-ls1]

New tires and wheels
